fiber laser cutting machine features :
1. X,Y axis Japan YASKAWA servo motor
2. Z axis Japan Panasonic servo motor
3. Taiwan HIWIN guide rail
4. Taiwan APEX Gear rack
5. Taiwan TBI ball screw
6. France Schneider electrical components
7. Cypcut control system
|
Material
|
thickness
(mm)
|
Speed
(meter/min)
|
Pressure
(mpa)
|
Focus
|
|
SS 201
|
1
|
9
|
0.8
|
-4
|
|
SS 201
|
2.2
|
2
|
1.2
|
-4
|
|
SS 304
|
1.3
|
7
|
0.9
|
-4
|
|
SS 304
|
1.8
|
3
|
1
|
-4
|
|
Carbon Steel
|
1.1
|
9(10)
|
0.8
|
-1
|
|
Carbon Steel
|
2.4
|
2.2
|
0.4
|
-3
|
|
Carbon Steel
|
2.8
|
1.5
|
0.4
|
-3.5
|
|
Carbon Steel
|
4
|
1.5(1.2)
|
0.4
|
-4
|
|
Application
|
LASER CUTTING Machine
|
|
Applicable Material
|
Metal
|
|
Condition
|
New
|
|
Cutting Area
|
3000mm*1500mm, 2000*4000MM
|
|
Graphic Format Supported
|
AI, PLT, DXF, BMP, Dst, Dwg, LAS, DXP
|
|
Cooling Mode
|
WATER COOLING
|
|
Control Software
|
Cypcut
|
|
Certification
|
ce, ISO, GS, Sgs, UL, CCC
|
|
Laser Source Brand
|
IPG
|
|
Laser Head Brand
|
Raytools
|
|
Servo Motor Brand
|
Yaskawa
|
|
Weight (KG)
|
4700KG
|
|
After-sales Service Provided
|
Engineers available to service machinery overseas
|
|
Machine type
|
fiber laser metal sheet cutter machine
|
|
Core Components
|
Motor
|
fiber laser cutting machine Cutting samples
packing and delivery :
